| Min Order | 3000 Meters |
| Trade Term | FOB,C&F,CIF,EXW |
| Payment Terms | T/T |
| Place of Origin | Wuhan |
| Means of Tranport | Ocean |
| Production Capacity | 50,000 Meters/Month |
| Packing | Customized |
Delivery Date | 7-15Days | Brand Name | Yuanfa |
Product Name | Thermal break Polyamide Strips, | Material | PA66GF25 |
Color | Black | Width | 54.0mm |
Density | 1.30±0.05 g/cm3 | Standard Length | 6 Meters/Piece |
Certificate | Certificate of ISO 9001:2015,CN09/20301 | Processing | High Precision Polyamide Extrusion |
Standard Carried | New National Standard:GB/T 23615.1-2017 | Applications | Aluminium Profiles,Thermally Broken |
YF-54.0-CT1 Thermal Insulation Bar: Reliable Energy-Saving Solution
Product Description:
The YF-54.0-CT1 thermal break strip is an extra-wide 54.0 mm insulating profile made from PA66 GF25 (polyamide with 25% glass fiber reinforcement), designed specifically for oversized aluminum curtain walls, structural façades, and heavy-duty window and door systems.
The CT1 profile features deep-tooth knurling, engineered to deliver strong mechanical interlocking during the crimping process. This ensures a secure and stable bond even under high wind loads, thermal expansion, or structural movement—making it an ideal solution for tall buildings, unitized curtain walls, and energy-efficient commercial façades.
Key Features:
Material: PA66 GF25 – high rigidity, thermal resistance, and excellent mechanical strength
Profile: CT1 – deep and aggressive knurling for enhanced grip and anti-slip performance
Width: 54.0 mm – suitable for ultra-wide aluminum systems with high insulation demands
Thermal Performance: Effectively breaks thermal bridging, lowering U-values and energy costs
Durability: UV-resistant, moisture-proof, and dimensionally stable under extreme conditions
Sustainability: RoHS compliant and recyclable, supporting green building certifications (e.g. LEED, BREEAM)
Typical Applications:
Super-large curtain wall systems and glass façades
High-rise commercial and institutional buildings
Passive house and near-zero energy building projects
Structural glazing and unitized aluminum panels
YF-54.0-CT1 offers the ultimate combination of width, strength, and insulation, enabling aluminum system manufacturers to meet the most demanding thermal and structural requirements in modern architecture.
