| Min Order | 3000 Meters |
| Trade Term | FOB,C&F,CIF,EXW |
| Payment Terms | T/T |
| Place of Origin | Wuhan |
| Means of Tranport | Ocean |
| Production Capacity | 50,000 Meters/Month |
| Packing | Customized |
Delivery Date | 7-15Days | Brand Name | Yuanfa |
Product Name | Thermal break Polyamide Strips, | Material | PA66GF25 |
Color | Black | Width | 32.5mm |
Density | 1.30±0.05 g/cm3 | Standard Length | 6 Meters/Piece |
Certificate | Certificate of ISO 9001:2015,CN09/20301 | Processing | High Precision Polyamide Extrusion |
Standard Carried | New National Standard:GB/T 23615.1-2017 | Applications | Aluminium Profiles,Thermally Broken |
Product Description:
The YF-32.5-Y3 thermal break strip is a 32.5 mm wide insulating profile made of PA66 GF25 (polyamide with 25% glass fiber reinforcement), designed to meet the needs of advanced architectural aluminum systems. With its Y3 profile, this model offers enhanced surface area and structural support, providing reliable performance in large-section windows, doors, and curtain walls.
The Y3 design is optimized for improved mechanical interlock during the crimping process, ensuring a tight and secure bond between the thermal barrier and the aluminum frame. It is ideal for use in energy-efficient buildings that demand both structural strength and high thermal insulation.
Key Features:
Material: PA66 GF25 – excellent strength, heat resistance, and long-term durability
Profile: Y3 – optimized for wide aluminum profiles and high-stress environments
Width: 32.5 mm – suitable for large-format thermal break systems
Thermal Performance: Reduces thermal bridging, improves energy efficiency
Weather-Resistant: Performs reliably in extreme temperatures, humidity, and UV exposure
Sustainable: RoHS compliant, recyclable, and aligned with green building certifications
Typical Applications:
Large-span curtain wall and façade systems
Oversized aluminum windows and sliding doors
Passive house and low-energy construction
Commercial, industrial, and institutional building projects
YF-32.5-Y3 combines structural integrity, thermal efficiency, and installation reliability, making it a trusted choice for demanding aluminum system designs.
