| Min Order | 3000 Meters |
| Trade Term | FOB,C&F,CIF,EXW |
| Payment Terms | T/T |
| Place of Origin | Wuhan |
| Means of Tranport | Ocean |
| Production Capacity | 50,000 Meters/Month |
| Packing | Customized |
Delivery Date | 7-15Days | Brand Name | Yuanfa |
Product Name | Thermal break Polyamide Strips, | Material | PA66GF25 |
Color | Black | Width | 32.0mm |
Density | 1.30±0.05 g/cm3 | Standard Length | 6 Meters/Piece |
Certificate | Certificate of ISO 9001:2015,CN09/20301 | Processing | High Precision Polyamide Extrusion |
Standard Carried | New National Standard:GB/T 23615.1-2017 | Applications | Aluminium Profiles,Thermally Broken |
Product Description:
The YF-32.0-Y thermal break strip is a 32.0 mm wide insulating profile, manufactured from PA66 GF25 (polyamide with 25% glass fiber reinforcement), engineered to deliver outstanding thermal insulation, mechanical strength, and dimensional stability for aluminum window, door, and curtain wall systems.
With its unique Y-profile, this model offers a balance between flexibility and reinforcement, making it ideal for wide-section aluminum systems that require precise fit and strong bonding during assembly. It is widely used in large-format curtain walls and energy-efficient façade solutions.
Key Features:
Material: PA66 GF25 – high mechanical strength, thermal resistance, and durability
Profile: Y-shape – designed for wide aluminum frames with optimized structural support
Width: 32.0 mm – suitable for heavy-duty thermal break applications
Thermal Barrier Performance: Effectively reduces thermal conductivity and energy loss
Weather & UV Resistant: Performs reliably in varying climates and environmental conditions
Sustainable & Safe: RoHS compliant and recyclable, contributing to green building goals
Applications:
Aluminum curtain walls and unitized façade systems
Wide-span doors and windows in commercial buildings
Passive houses and energy-saving residential projects
Industrial and institutional aluminum structures
YF-32.0-Y is the ideal thermal break solution for architects and aluminum system designers seeking a reliable, high-performance insulating profile for demanding applications.
