| Min Order | 3000 Meters |
| Trade Term | FOB,C&F,CIF,EXW |
| Payment Terms | T/T |
| Place of Origin | Wuhan |
| Means of Tranport | Ocean |
| Production Capacity | 50,000 Meters/Month |
| Packing | Customized |
Delivery Date | 7-15Days | Brand Name | Yuanfa |
Product Name | Thermal break Polyamide Strips, | Material | PA66GF25 |
Color | Black | Width | 25.3mm |
Density | 1.30±0.05 g/cm3 | Standard Length | 6 Meters/Piece |
Certificate | Certificate of ISO 9001:2015,CN09/20301 | Processing | High Precision Polyamide Extrusion |
Standard Carried | New National Standard:GB/T 23615.1-2017 | Applications | Aluminium Profiles,Thermally Broken |
Product Overview
The YF-25.3-CT2 is a high-precision polyamide thermal break strip, specially designed for premium aluminum windows, doors, and curtain wall systems requiring superior insulation performance and structural stability. With its 25.3 mm width and enhanced CT2 geometry, it provides exceptional bonding strength and thermal barrier properties.
✅ Excellent Thermal Insulation
Made from top-grade PA66 GF25, the YF-25.3-CT2 effectively reduces thermal bridging, boosting the energy efficiency of aluminum profiles.
✅ Enhanced CT2 Tooth Design
The “CT2” knurling-friendly geometry ensures secure mechanical interlocking with aluminum frames, delivering higher pull-out resistance and better stress distribution.
✅ High Dimensional Stability
Maintains precise shape and performance even under extreme temperatures and long-term exposure.
✅ Durable Weather & UV Resistance
Designed for harsh climate zones — with proven resistance to aging, moisture, and UV degradation.
✅ Seamless Integration
Supports standard knurling and crimping processes for fast, efficient, and reliable assembly.
Material: PA66 GF25 (25% Glass Fiber Reinforced Polyamide 66)
Width: 25.3 mm
Profile: CT2 (Custom Tooth Profile for improved grip)
Color: Standard black (other colors available)
Operating Temperature: -40°C to +180°C
Thermal Conductivity: ≤ 0.3 W/m·K
✔ Aluminum windows & doors
✔ Thermally broken curtain wall systems
✔ High-end facades & commercial building envelopes
✔ Passive house & low-energy architecture projects
